Quick-release connector Screws Faston terminals, male 2.8
Faston terminals, male 2.8
Quick-release
connector
Screws
N.B.:
If the user terminal is used in the room, the connection to the controller is provided by means of exible wires with a maximum
length of 30 m and section 1 mm² (2 conductors, see terminal 1 and 2 of the regulator). It is essential to use a twisted shielded
cable. The shielding must be connected to earth at a single point, to the fan coil unit eart.
15 - WIRING DIAGRAM
EN7515935-00 EN - 20
