CIGWELD Transarc Tradesman HD

Questions and Answers

M
Margaret HudsonAug 4, 2025
What to do if there is undercut with my CIGWELD Welding System?
- T
  Thomas DyerAug 4, 2025
  Undercut in CIGWELD Welding System can occur if the welding current is too high. Try reducing the welding current. Also, a long welding arc can cause undercut; shorten the arc length. Ensure the electrode angle is correct, maintaining at least a 45° angle to the vertical face. If the joint preparation restricts the electrode angle, allow more room for manipulation. Using a smaller gauge electrode and pausing at the edge of the weave to allow weld metal build-up can also help.
C
Christopher VincentAug 11, 2025
How to fix gas pockets in CIGWELD Welding System?
- T
  travisaliciaAug 11, 2025
  Porosity in CIGWELD Welding System may be due to damp electrodes; dry them before use. If the welding current is too high, reduce it. Also, surface impurities like oil, grease, or paint can cause porosity; clean the joint before welding.
R
Robert PooleAug 17, 2025
What causes slag inclusion in CIGWELD Transarc Tradesman HD Welding System and how to prevent it?
- Y
  yreidAug 17, 2025
  Slag inclusion in CIGWELD Welding System can occur if non-metallic particles are trapped in undercut from a previous run. Clean the slag and cover with a run from a smaller diameter electrode. Ensure the joint preparation isn't too restricted, allowing for adequate penetration and slag removal. Chip or grind out any irregular deposits that trap slag. Use a smaller electrode with sufficient current for penetration, and remove all slag from corners. Clean the joint to remove rust or mill scale that prevents full fusion. Use electrodes designed for the welding position to control slag properly.
V
Victoria SmithAug 22, 2025
Why is there a gap in the root of my CIGWELD Transarc Tradesman HD weld?
- K
  Kimberly LeeAug 22, 2025
  If the weld metal fails to fill the root of the weld in your CIGWELD Welding System, it might be due to a welding current that is too low. Try increasing the welding current. Also, if the electrode is too large for the joint, use a smaller diameter electrode. If there is insufficient gap, allow a wider gap. Finally, ensure you are using the correct build-up sequence.
B
Benjamin EvansAug 28, 2025
How to prevent cracks in CIGWELD Welding System weld metal?
- C
  Carmen SchwartzAug 28, 2025
  Cracking in the weld metal of your CIGWELD Welding System shortly after solidification can be due to joint rigidity. Redesign the joint to relieve stress or use crack-resistant electrodes. Insufficient throat thickness can also cause cracking; travel slightly slower to allow greater build-up. If the cooling rate is too high, preheat the plate and allow it to cool slowly.

Summary

1. Introduction

1.1 Manual Introduction

Overview of the manual's content and structure, including notes, cautions, and warnings.

1.2 Important Safety Precautions

Gases, Fumes, and Electric Shock Hazards

Details the dangers of welding gases, fumes, and electric shock, with necessary precautions.

Fire, Noise, and Arc Ray Hazards

Covers risks of fire, explosion, hearing loss from noise, and eye/skin damage from arc rays.

2. Electromagnetic Compatibility

2.1 User Responsibility & Area Assessment

User's role in managing EMC and assessing the environment for interference.

2.3 Reducing EMC Emissions

Provides methods for reducing electromagnetic emissions from the welding equipment.

3. General Information

3.1 Transarc Tradesman HD Overview

Detailed description of the Transarc Tradesman HD welding machine features and capabilities.

3.2 Transarc 400 S Overview

Detailed description of the Transarc 400S welding machine features and capabilities.

3.3 User Responsibility & Duty Cycle

Explains user obligations and the concept of welding power source duty cycle.

3.5;3.6 Warranty Information

Outlines the terms, conditions, and schedule of the product warranty.

4. Safe Practices for Welding Equipment

4.1 Operator Precautions

Key precautions operators must take during welding for safety and equipment protection.

4.2 Personal Protection & Face Shields

Recommends PPE and guidance on selecting welding face shields and filter lenses.

5. Resuscitation for Electric Shock Victims

5.1 Resuscitation Procedures

Step-by-step instructions for performing resuscitation on electric shock victims.

6. Specifications

6.1 Transarc Tradesman HD Specifications

Detailed technical specifications for the Transarc Tradesman HD welding unit.

6.2 Transarc 400 S Specifications

Detailed technical specifications for the Transarc 400S welding unit.

7. Installation Recommendations

7.1 Environment, Location, and Ventilation

Guidelines for selecting a suitable environment, location, and ensuring proper ventilation.

7.4 Mains Supply Voltage Requirements

Recommendations for proper mains supply voltage connection and power requirements.

8. Operation

8.1 Transarc Tradesman HD Controls

Description of the controls and terminals for the Transarc Tradesman HD model.

8.2 Transarc 400 S Controls

Description of the controls and terminals for the Transarc 400S model.

9. Arc Welding Electrodes

9.2 Types of Electrodes

Classification and applications of various CIGWELD electrodes for different metals.

9.3 Electrode Size, Storage, and Polarity

Guidance on selecting, storing, and connecting electrodes correctly.

9.6 Material Welding Effects

Discusses the effects of welding different types of metals and alloys.

10. Arc Welding Practice

10.1 Welding Positions & Joint Prep

Details welding positions and joint preparation techniques for sound welds.

11. Arc Welding Technique

11.1 Welder Positioning and Comfort

Advice on achieving a comfortable and efficient posture for welding.

11.2 Striking the Arc and Arc Length

Techniques for initiating the arc and maintaining proper arc length.

11.3 Rate of Travel and Joint Making

Guides on travel speed and methods for creating welded joints.

12. Distortion

12.1 Causes of Distortion

Explains distortion due to weld metal contraction and parent metal expansion.

12.2 Overcoming Distortion Effects

Methods to minimize distortion, including peening, preheating, and presets.

13. Routine Maintenance & Inspection

13.1 Cleaning the Welding Power Source

Instructions for cleaning the welding power source to ensure optimal performance.

14. Basic Troubleshooting

14.1 Welding Problems

Diagnoses common welding issues like porosity, cracks, undercut, and slag inclusion.

14.2 Power Source Problems

Troubleshooting steps for power source issues like no arc, low current, or fan failure.

14.3 Key Spare Parts

Lists essential spare parts for the welding machines and their part numbers.

14.4 Exploded Views

Transarc Tradesman HD Exploded View

Diagram showing the components of the Transarc Tradesman HD welding machine.

Transarc 400 S Exploded View

Diagram showing the components of the Transarc 400S welding machine.

14.5 Wiring Diagrams

Transarc Tradesman HD Wiring Diagram

Electrical schematic illustrating the wiring of the Transarc Tradesman HD.

Transarc 400 S Wiring Diagram

Electrical schematic illustrating the wiring of the Transarc 400S.
