0-5492 9-3 KEY SPARE PARTS
9.03 E-180 MIG Torch 3m (P/N W4018800) Key Spare Parts
Art # A-13453
2
1
3
4
6
5
7
Figure 9-3
MIG TORCH KEY SPARE PARTS
ITEM PART NUMBER DESCRIPTION
1 W6000600 Nozzle
2
OTW11/23/R Contact Tip 0.6mm
OTW11/30/R Contact Tip 0.8mm
OTW11/35/R Contact Tip 0.9mm
OTW11/40/R Contact Tip 1.0mm
OTW11/45/R Contact Tip 1.2mm
3 W6000606 Diffuser
4 W6000607 Conductor Tube
5 W6000608 Trigger Assembly
6 W6000609 Handle Mouldings (includes handle mouldings, screws, cable
support)
7
WS1240015/R Conduit Liner Steel 5m, 0.6-1.0mm Blue (hard wires)
WS1240031/R Conduit Liner Steel 4m, 1.0-1.2mm Red (hard wires)
WS1260026/R Conduit Liner Teflon 4m, 0.8-1.2mm Red (soft wires)
WS0010304/R Jump Liner 1.0-1.2mm
Table 9-3
