2-6
Manual No 0-5072
welDskIll 250, 350 INTRODUCTION
December 1, 2008
2.09 WeldSkill 350 MIG Power Source Specifications
Identification, Weights & Measures WeldSkill 350
Plant Assembly W1003500
Plant Dimensions
(including cylinder carrier & wheels)
H 980mm x W 440mm x D 988mm
Power Source Part Number W1003501
Power Source Mass 112 kg
Energy Input (Refer NOTE Below) WeldSkill 350
Input Cable Requirements 1.5mm
2
3 core + earth heavy duty R90
insulation type
Supply Input Voltage 415 VAC
Number of Phases & Frequency 3 Phase 50 Hz
Rated Input Current @ 100% Duty Cycle
14 A
Rated kVA @ 100% Duty Cycle 10 kVA
Maximum Input Current 25 A
Generator Requirements
20 kVA
Supply VA @ no load 3700 VA
Supply VA @ max. output 18 kVA
Rated Outlet Maximum Duty Cycle 25 A
Recommended Fuse Size
25 A
Welding Output (Refer NOTE Below) WeldSkill 350
Open Circuit Voltage Range 17 to 42 V
Output Current Range 30 – 380 A
Rated Output Duty Cycle 350A @ 30%
100% Duty Cycle Output Rating 205 A
Operating Temperature Range 0ºC - 40ºC
Duty Cycle Period 10 minutes
Number of Output Voltage Switch Settings
24
Maximum Inlet Gas Pressure 1.2 MPa (gas hose)
Suitable Gas Types Argon based mixed gases & C0
2
Wire Size Range Hard Wire:
Fluxcored Wire:
0.6mm – 1.2mm
1.0 mm – 1.2mm
Table 2-2 WeldSkill 350 Power Source Specifications
The Rated Input Current should be used for the determination of cable size & supply requirements.
Motor start fuses or thermal circuit breakers are recommended for this application. Check local
requirements for your situation in this regard.
Generator Requirements at the Maximum Output Duty Cycle.
Due to variations that can occur in manufactured products, claimed performance, voltages, ratings, all capacities, measure-
ments, dimensions and weights quoted are approximate only. Achievable capacities and ratings in use and operation will de-
pend upon correct installation, use, applications, maintenance and service.
