CIGWELD weldskill 250 - Appendices, Warranty, and Support; Appendices: Spare Parts and Curves

A-1 Manual No 0-5072
appendix weldskill 250, 350
December 1, 2008
APPENDIX 1:
KEY SPARE PARTS
Part No Description Part No Description
W7004526 Main Transformer W7004513 Control Transformer
W7004501 Contactor W7004532 Thermostat 150°C,WS250
W7004502 PCB Control W7004515 Inch switch
W7004503 Solenoid Valve,36VAC W7004538 Thermostat 105°C,WS250
W7004504 Wire Reel Hub W7004517 Resistor 0.5 ohm 30W
W7004505 Switch,On/Off,415V W7004518 Switch 2T/4T/Spot
W7004506 Fan Assembly, 220V W7004519 Pot,5K,Wire Speed
W7004528 Inductor Assembly W7004520 Pot,100K,Burnback
W7004529 Rectifier 300A W7004521 Overheat Indicator Light
W7004530 Switch Coarse Voltage W7004522 Power Indicator Light
W7004511 Wire Drive Assembly,WS250 W7004523 Fuse holder
W7004512 Socket, 50mm Dinse W7004524 Fuse 8A
W7004535 Fuse 3A
Table Appendix 1-1: Key Spare Parts for 250
Part No Description Part No Description
W7004500 Main Transformer W7004537 Control Transformer
W7004501 Contactor W7004514 Thermostat 115°C,WS350
W7004502 PCB Control W7004515 Inch switch
W7004503 Solenoid Valve,36VAC W7004516 Thermostat 110°C,WS350
W7004504 Wire Reel Hub W7004517 Resistor 0.5 ohm 30W
W7004505 Switch,On/Off,415V W7004518 Switch 2T/4T/Spot
W7004506 Fan Assembly,220V W7004519 Pot,5K,Wire Speed
W7004507 Inductor Assembly W7004520 Pot,100K,Burnback
W7004508 Rectifier 400A W7004521 Overheat Indicator Light
W7004509 Switch, Coarse Voltage W7004522 Power Indicator Light
W7004510 Switch, Fine Voltage W7004523 Fuse holder
W7004536 Wire Drive Assembly,WS350 W7004524 Fuse 8A
W7004512 Socket, 50mm Dinse W7004525 Fuse 3A
Table Appendix 1-2: Key Spare Parts for 350
