3.1 Key menu - Coffee selection
Press one of the coffee dispensing keys (32) (the relative led
will remain on). The following message will appear on the
display:
The following coffee selection parameters can be modied:
- repetition * (it represents the number of distributions of
the selected drink, from 001 to 099);
- water dose (volumetric dosage pulses, from 0 to 999, with
increments of 1);
- coffee dose... (coffee dose grinde ...impulses, 0 ÷ 200 with
increments of 1);
- water start (volumetric dosage pulses, from 0 to 999, with
increments of 1).
The components - * - are applied only in some produit
congurations
The dose for making a cup of coffee can be composed of
grounds taken from both hoppers, which has the advantage
of less time needed for grinding.
The dose setting for both grinders has a eld range of + 10
of the value set in the technical programming menu.
Example
technical programming customer programming
coffee dose MM1 045 coffee dose MM1 035÷055
coffee dose MM2 020 coffee dose MM2 010÷030
3.2 Key menu - Cappuccino selection
Press one of the cappuccino dispensing keys (32) (the rela-
tive led will remain on). The following message will appear on
the display:
The following cappuccino selection parameters can be modi-
ed:
- repetition * (it represents the number of distributions of the
selected drink, from 001 to 099);
- milk dose (milk dispensing time: 0 ÷ 60 seconds, with
increments of 0.1);
- emulsion ((foamed milk dispensing time, from 0 to 60, with
increments of 0.1 seconds);
- cold milk dose (cold milk dose; from 0 to 20 with increments
of 0.1 seconds);
- water dose (volumetric dosage pulses, from 0 to 999, with
increments of 1);
- coffee dose... (coffee dose grinde ...impulses, 0 ÷ 200 with
increments of 1);
The components - * - are applied only in some produit
congurations
The dose for making a cup of coffee can be composed of
grounds taken from both hoppers, which has the advantage
of less time needed for grinding.
The dose setting for both grinders has a eld range of + 10
of the value set in the technical programming menu.
+


 KEY MENU
Type 1 cappuccino
repetition 001
Milk dose 04.0
Emulsion 03.0
Cold milk dose 05.0
3.3 Key menu - Milk selection
Press one of the milk dispensing keys (32). The related LED
remains on and does not blink. The display appears as fol-
lows:
The following cappuccino selection parameters can be modi-
ed:
- repetition * (it represents the number of distributions of the
selected drink, from 001 to 099);
- milk dose (milk dispensing time: 0 ÷ 60 seconds, with
increments of 0.1););
- emulsion ((foamed milk dispensing time, from 0 to 60, with
increments of 0.1 seconds);
- cold milk dose (cold milk dose; from 0 to 20 with increments
of 0.1 seconds);
The components - * - are applied only in some produit
congurations
+


 KEY MENU
Type milk
repetition 001
Milk dose 07.0
Emulsion 05.0
Cold milk dose 05.0
+


KEY MENU
Type 1 coffee
repetition 001
Water dose 110
MM1 cof, dose 043
MM2 cof, dose 000
