CipherLab 1100 User Manual

123
Update
0 1 2 3 4 5 6 7 8
0 F2 SP 0 @ P ` p

1 INS F3 ! 1 A Q a q

2 DLT F4 " 2 B R b r

3 Home F5 # 3 C S c s

4 End F6 $ 4 D T d t

5 Up F7 % 5 E U e u

6 Down F8 & 6 F V f v

7 Left F9 ' 7 G W g w

8 BS F10 ( 8 H X h x

9 HT F11 ) 9 I Y i y

A LF F12 * : J Z j z
B Right ESC + ; K [ k {
C PgUp Exec , < L \ l |
D CR CR* - = M ] m }
E PgDn . > N ^ n ~
F F1 / ? O _ o Dly ENTER*
Note: (1) ~: Digits of numeric keypad.
(2) CR*/ENTER*: ENTER key on the numeric keypad.
Appendix II
KEYBOARD WEDGE TABLE

CipherLab 1100 Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Pitch reading angle	-70 - 70 °
Optical sensor resolution	3648 pixels
Light levels (direct sunlight)	5 - 95 lx
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), MSI, Pharmacode, Plessey, Telepen, U.P.C.
2D (matrix & stacked) barcodes supported	-
Connectivity technology	Wired
Product color	Gray
Housing material	Polyurethane
Input voltage	5 V
Power consumption (standby)	0.06 W
Power consumption (typical)	0.19 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	145 mm
Width	93 mm
Height	74 mm
Weight	165 g
