CipherLab 1100 User Manual

27
Update
In order to establish a proper connection between your computer and the scanner, we
suggest that you follow these instructions –
1) Connect the interface cable to your computer.
 If using the RS-232 cable, join the power supply cord.
2) Have the scanner read the “Enter Setup” barcode to enter the configuration mode.
3) Have the scanner read the associated barcodes to activate the desired interface.
See the following sections for output interfaces supported.
 If you are connecting the scanner to the USB port of the host computer via USB
HID cable (part # 307), refer to
2.1 Keyboard Wedge for related settings.
 If you are connecting the scanner to the USB port of the host computer via USB
Virtual COM cable (part # 308), refer to
2.2 RS-232 related settings.
 If you are connecting the scanner to the IBM POS 4683/4694 via the converter
cable (part # 346), refer to
2.1 Keyboard Wedge for related settings.
4) Have the scanner read the barcodes for related settings.
5) Have the scanner read the “Update” barcode to exit the configuration mode.
Note: By default, the output interface is set to “Keyboard Wedge”.
IN THIS CHAPTER
2.1 Keyboard Wedge ....................................................... 28
2.2 RS-232 .................................................................... 39
2.3 Wand Emulation ........................................................ 42
Chapter 2
SELECTING OUTPUT INTERFACE

CipherLab 1100 Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Pitch reading angle	-70 - 70 °
Optical sensor resolution	3648 pixels
Light levels (direct sunlight)	5 - 95 lx
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), MSI, Pharmacode, Plessey, Telepen, U.P.C.
2D (matrix & stacked) barcodes supported	-
Connectivity technology	Wired
Product color	Gray
Housing material	Polyurethane
Input voltage	5 V
Power consumption (standby)	0.06 W
Power consumption (typical)	0.19 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	145 mm
Width	93 mm
Height	74 mm
Weight	165 g
