CipherLab 1100 User Manual

16
Enter Setup
1000/1090+/1100/1105 Barcode Scanner User Guide
1.3 BEEPER
The scanner has a buzzer to provide user feedback in various operating conditions.
Beeping
Meaning
One long beep, high tone Power on, with red LED on (1 second) and off quickly
One short beep, high tone
 Programmable, default to 4 KHz
Good Read, with red LED on and off quickly
Six short beeps
 High-low tone repeats three times
 Enter Configuration Mode, with green LED on
 Exit Configuration Mode
Two beeps, high-low tone Setup barcode read successfully
One short beep, high tone More setup barcode required
One long beep, low tone Configuration error (Wrong barcode…)

CipherLab 1100 Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Pitch reading angle	-70 - 70 °
Optical sensor resolution	3648 pixels
Light levels (direct sunlight)	5 - 95 lx
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), MSI, Pharmacode, Plessey, Telepen, U.P.C.
2D (matrix & stacked) barcodes supported	-
Connectivity technology	Wired
Product color	Gray
Housing material	Polyurethane
Input voltage	5 V
Power consumption (standby)	0.06 W
Power consumption (typical)	0.19 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	145 mm
Width	93 mm
Height	74 mm
Weight	165 g
