Chapter 2 Selecting Output Interface
Keyboard Wedge
By default, the keyboard type is set to PCAT (US). The following keyboard types are supported —
No. Keyboard Type No. Keyboard Type
1 PCAT (US) 15 PS55 001-81
2 PCAT (French) 16 PS55 001-2
3 PCAT (German) 17 PS55 001-82
4 PCAT (Italian) 18 PS55 001-3
5 PCAT (Swedish) 19 PS55 001-8A
6 PCAT (Norwegian) 20 PS55 002-1, 003-1
7 PCAT (UK) 21 PS55 002-81, 003-81
8 PCAT (Belgium) 22 PS55 002-2, 003-2
9 PCAT (Spanish) 23 PS55 002-82, 003-82
10 PCAT (Portuguese) 24 PS55 002-3, 003-3
11 PS55 A01-1 25 PS55 002-8A, 003-8A
12 PS55 A01-2 (Japanese) 26 IBM 3477 Type 4 (Japanese)
13 PS55 A01-3 27 PS2-30
14 PS55 001-1 28 IBM 34XX/319X, Memorex Telex 122 Keys

CipherLab 1100 Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Pitch reading angle	-70 - 70 °
Optical sensor resolution	3648 pixels
Light levels (direct sunlight)	5 - 95 lx
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), MSI, Pharmacode, Plessey, Telepen, U.P.C.
2D (matrix & stacked) barcodes supported	-
Connectivity technology	Wired
Product color	Gray
Housing material	Polyurethane
Input voltage	5 V
Power consumption (standby)	0.06 W
Power consumption (typical)	0.19 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	145 mm
Width	93 mm
Height	74 mm
Weight	165 g
