CipherLab 8230 Reference Manual

93
Model Designation
8600 8630 8660
Performance
CPU ARM Cortex-M3
Memory
 Program memory – 16 MB flash
 Data memory – onboard SRAM, options include 8 or 16 MB
Expansion micro SD Slot with SDHC support
Main Battery Rechargeable Li-ion battery – 3.7 V, 1100/2200 mAh
Expected Battery Life*
(1100/2200 mAh)
32/64 hrs
12/24**
hrs
17/34**
hrs
18/36 hrs
Data Retention 25 days (Rechargeable Lithium battery – 3.0V, 18 mAh)
Wireless Communications
WLAN − 802.11b/g/n −
WLAN Security −
WEP, EAP, WPA-PSK,
WPA2-PSK
−
WPAN −
Bluetooth 4.0 Dual Mode
(2.1+EDR/BLE)
Bluetooth 4.0 Dual Mode
(2.1+EDR/BLE)
Bluetooth Profile − SPP, DUN, HID SPP, DUN, HID
Data Capture
Barcode Reader
 CCD (linear imager)
 Standard Laser
 2D Imager
RFID Reader (optional)
13.56MHz HF band (supports ISO 14443A/14443B/15693)
Physical Characteristics
Display
2.83” color LCD, 240x320 pixels, TFT with LED backlight
programmable
GPS (optional) GPS JN3, Internal antenna
Keypad 29/39 keys, LED backlight programmable
LED Indication 2 programmable dual-color LED indicators –
 Red/Green: charging & decoding
 Blue/Green: wireless communication
Audio 0.5W, 80dB@2KHz speaker
Vibrator 0.45G, programmable
Dimensions 170 x 60 x 30 mm (L x W x H)
Weight 240g*** approx.
SPECIFICATIONS

CipherLab 8230 Specifications

General

Brand	CipherLab
Model	8230
Category	Handhelds
Language	English
