8600 Series Mobile Computer Reference Manual
Warning! The contents of the data memory (SRAM) will be wiped out after test.
3.3.6 ECHO TEST
After a physical connection is established properly, run a test utility on your computer
and start the test on your mobile computer. Select a desired baud rate if necessary.
 To stop and exit the test, press [ESC].
Interface
Description Test Utility
RS-232 This echo test is to verify connectivity via the RS-232 cable
between the mobile computer and a host computer.
EchoTest.exe
Fast VPort This echo test is to verify the connectivity via the Fast VPort
cable between the mobile computer and a host computer.
EchoTest.exe
This echo test is to verify connectivity via the USB cable
between the mobile computer and a host computer.
 USB VCOM Echo — The mobile computer works as a
generic USB device.
EchoTest.exe for
Virtual COM
 USB HID — The mobile computer works as an input
device; select keyboard type and Caps Lock status for
running a test.
Any text editor for
HID
USB
 USB VCOM_CDC Echo — The mobile computer works as
a generic USB device.
EchoTest.exe for
Virtual COM
3.3.7 VIBRATOR
Select this item to test the vibrator.
 To stop and exit the test, press [ESC].
3.3.8 RFID
Select this item to test the RFID Reader.
 Press [ESC] to exit.
3.3.9 GPS
Select this item to test the GPS receiver of the device.
Received Information
Description
Latitude Displays the latitude where the device is located.
Longit. Displays the longitude where the device is located.
Speed Displays the moving speed in kilometers per hour.
Altitude Displays the altitude in meters.
