Circutor CVM-A1000 - 5�5�2�- Event Log

5�5�2�- EVENT LOG
This screen shows the log of the last 50 events occurring in the device and the installed
expansion modules, including a brief description and the date and time of the event.
Figure 214:Event log�
>
>
<
<
>
<
>
<
←
←
Main
menu
Back
Next
Previous
Figure 215:Event log menu�
Use the keys and to select the different options.
To conrm the selection, press the key .
If no button is pressed for 5 minutes, the display screen changes automatically to the default
screen, which displays the voltage measurement of 4 parameters.
The event log can be deleted on the Parameter reset screen of the setup menu ( “5.7.20.- PA-
RAMETER RESET.”)
