I
R
, denotes nominal rms load current of the transformer,
h, denotes harmonic order.
Peak factor
The Peak factor is the ratio between the peak value and the RMS value of a periodic voltage
or current. The purpose of the peak factor is to give an idea of the wave peak and it is used
primarily for current waves.
% =
|
|
|
|
100
% =
|
|
|
|
100
=
1 +
1 +
=
|
|
100
Ecuación 4: Peak factor�
In a perfect sinusoidal wave, the peak value is √2 times greater than the RMS value; therefore
the peak factor is 1�41. For waves with very high peak values, the peak factor will be over 1�41
4.3.- KEYPAD FUNCTIONS
The CVM-A has 3 keys that allow you to browse the various screens and program the device.
Table 14: Function of keys�
Key Keystroke
Shifting to the left
Shifting to the right
Select parameter / Enter programming menu
47
Instruction Manual
CVM-A1000 - CVM-A1500
