29
ATM Line Card Installation and Configuration
OL-13004-01
Verifying and Troubleshooting Line Card Installation
Table 12 lists other messages displayed on the line card alphanumeric LED displays.
IOS
VGET
2
Line card is obtaining the Cisco IOS version. RP IOS software
IOS
RUN
Line card is enabled and ready for use. RP IOS software
IOS
STRT
Cisco IOS software is being launched. RP IOS software
IOS
TRAN
Cisco IOS software is transitioning to active. RP IOS software
IOS
UP
Cisco IOS software is running. RP IOS software
1. The entire LED sequence shown in Table 11 might occur too quickly for you to read; therefore, this sequence is provided in
this tabular form as a baseline for how a line card should function at startup.
2. This LED sequence only appears in Cisco IOS release 12.0(24)S or later.
3. The fabric downloader loads the Cisco IOS software image onto the line card.
Table 11 Alphanumeric LED Messages During a Typical Initialization Sequence (continued)
LED Display
1
Meaning Source
Table 12 Other Alphanumeric LED Messages
LED Display Meaning Source
MAL
FUNC
Line card malfunction reported by field diagnostics. RP
MISM
ATCH
1
Line card type mismatch in paired slots. RP
PWR
STRT
1
Line card has been newly powered on. RP
PWR
ON
Line card is powered on. RP
IN
RSET
In reset. RP
RSET
DONE
Reset complete. RP
MBUS
DNLD
MBus agent downloading. RP
MBUS
DONE
MBus agent download complete. RP
ROMI
DONE
Acquisition of ROM image complete. RP
MSTR
WA I T
Waiting for mastership determination. RP
CLOK
WA I T
Waiting for slot clock configuration. RP
