2-19
Cisco Aironet 1240AG Series Access Point Hardware Installation Guide
OL-8371-05
Chapter 2 Installing the Access Point
Securing the Access Point
Step 3 Place your padlock (user supplied) through the padlock hole in the security hasp’s padlock flange
(see Figure 2-11).
Figure 2-11 Security Hasp and Padlock
Step 4
Push the padlock into the recessed opening between the access point and the mounting plate.
Note When attaching the mounting plate to a vertical surface, place the security cable bracket end of the
mounting plate on the bottom.
1 Security hasp 2 Pad lock
135442
2.4 GHz RIGHT / PRIMARY
2.4 GHz LEFT
1
2
