• USB drive formatted with FAT32
• Boot kickstart image from ROMMON for discovery recovery purposes
• Copy files to and from workspace:/ and volatile:/ within local-mgmt. The most relevant files are:
• Core files
• Ethanalyzer packet captures
• Tech-support files
• Security module log files
• Platform bundle image upload using download image usbA:
The Type A USB port does not support Cisco Secure Package (CSP) image upload support.
Network Ports
The Secure Firewall 3100 chassis has a network module slot that supports the following network modules:
• 8-port 1/10-Gb SFP
• 8-port 1/10/25-Gb SFP
• 6-port 1-Gb SFP SX multimode hardware bypass
• 6-port 10-Gb SFP SR multimode hardware bypass
• 6-port 10-Gb SFP LR single mode hardware bypass
• 6-port 25-Gb SFP SR multimode hardware bypass
• 6-port 25-Gb SFP LR single mode hardware bypass
• 8-port 10/100/1000Base-T hardware bypass
• 4-port 40-Gb QSFP
The 4-port 40-Gb and 8-port 25-Gb network modules are supported only on the
3130 and 3140.
Note
Factory Reset Button
The Secure Firewall 3100 chassis has a recessed reset button that resets the system to the factory default.
All previous configuration is erased after pressing the button down for five seconds. The following
occurs:
• ROMMON NVRAM is cleared and returned to default.
• All extra images are removed; the current running image remains.
• FXOS logs, core files, SSH keys, certificates, FXOS configuration, and Apache configuration are
removed.
Cisco Secure Firewall 3110, 3120, 3130, and 3140 Hardware Installation Guide
10
Overview
Front Panel
