For More Information
• See 1-Gb SX/10-Gb SR/10-Gb LR/25-Gb SR/25-Gb LR Network Module with Hardware Bypass,
on page 22 for a description of the 1/10/25-Gb network module.
• See Hardware Bypass Network Modules, on page 19 for a description of hardware bypass.
• See 40-Gb Network Module, on page 17 for a description of the 40-Gb network module.
• See 1/10/25-Gb Network Module, on page 15 for a description of the 1/10/25-Gb network module.
• See Install, Remove, and Replace the Network Module, on page 65 for the procedure for removing
and replacing network modules.
1-GbSX/10-GbSR/10-GbLR/25-GbSR/25-GbLRNetworkModule
with Hardware Bypass
The Secure Firewall 3100 chassis has one network module slot. Network modules are optional, removable
I/O modules that provide either additional ports or different interface types. The network module plugs into
the chassis on the front panel. See Front Panel, on page 8 for the location of the network module slot on the
chassis.
There are five PIDs for this network module: FPR3K-XNM-6X1SXF, FPR3K-XNM-6X10SRF,
FPR3K-XNM-6X10LRF, FPR3K-XNM-6X25SRF, and FPR3K-XNM-6X25LRF. The 1-Gb SX/10-Gb
SR/10-Gb LR/25-Gb SR/25-Gb LR hardware bypass network module has six ports that are numbered from
top to bottom, left to right. Pair ports 1 and 2, 3 and 4, and 5 and 6 to form hardware bypass paired sets. In
hardware bypass mode, data is not processed by the Secure Firewall 3100 but is routed to the paired port.
This network module has built-in SPF transceivers. Hot swapping and field replacement of transceivers is not
supported.
The hardware and the system support hot swapping if you are replacing a network module with the same type
of network module. You must first disable the network port and then reenable it after replacement. If you
replace the 1/10/25-Gb network module with another supported network module, you must reboot the chassis
so that the new network module is recognized. See the configuration guide for your operating system for the
detailed procedures for managing network modules.
Note
Make sure you have the correct firmware package and software version installed to support this network
module. See the configuration guide for your software for the procedure to verify your firmware package and
software version. See the Cisco Secure Firewall Threat Defense Compatibility Guide and the Cisco Secure
Firewall ASA Compatibility guide, which provide Cisco software and hardware compatibility, including
operating system and hosting environment requirements, for each supported version
Note
The following figure shows the front panel of the 1/10/25-Gb network module.
Cisco Secure Firewall 3110, 3120, 3130, and 3140 Hardware Installation Guide
22
Overview
1-Gb SX/10-Gb SR/10-Gb LR/25-Gb SR/25-Gb LR Network Module with Hardware Bypass
