• See 10/100/1000Base-T Network Module with Hardware Bypass, on page 20 for a description of
the 10/100/1000Base-T network module.
• See Hardware Bypass Network Modules, on page 19 for a description of hardware bypass.
• See Install, Remove, and Replace the Network Module, on page 65 for the procedure for removing
and replacing network modules.
40-Gb Network Module
The Secure Firewall 3100 chassis has one network module slot. Network modules are optional, removable
I/O modules that provide either additional ports or different interface types. The network module plugs into
the chassis on the front panel. See Front Panel, on page 8 for the location of the network module slot on the
chassis.
There is one PID for this network module: FPR3K-XNM-4X40G. The FPR3K-XNM-4X40G supports 40-Gb
operation and is supported on the 3130 and 3140. This network module provides full-duplex Ethernet traffic
per port. The 40-Gb network module has four QSFP+. The 40-Gb ports are numbered left to right, Ethernet
X/1 through Ethernet X/4. See Supported SFP/SFP+/QSFP+ Transceivers , on page 28 for the list of
Cisco-supported transceivers.
Starting with FTD 7.2 and ASA 7.18.1, you can break the four 40-Gb ports into four 10-Gb ports using the
supported breakout cables. With the four-port 40-Gb network module, you now have 16 10-Gb interfaces.
The added interfaces are Ethernet 2/1/1 through Ethernet 2/1/4.
The hardware and the system support hot swapping if you are replacing a network module with the same type
of network module. You must first disable the network port and then reenable it after replacement. If you
replace the 40-Gb network module with another supported network module, you must reboot the chassis so
that the new network module is recognized. See the configuration guide for your operating system for the
detailed procedures for managing network modules.
Note
Although you can install the 4-port 40-Gb network in the Secure Firewall 3110 and 3120, the software does
not recognize it because it is not supported.
Note
The following figure shows the front panel of the 40-Gb network module.
Cisco Secure Firewall 3110, 3120, 3130, and 3140 Hardware Installation Guide
17
Overview
40-Gb Network Module
