3140313031203110Feature
Two Nonvolatile Memory Express (NVMe) SSD slots
Ships with one 900-GB SSD installed in slot 1. You can order a second RAID1 SSD
for slot 2. The RAID1 SSD is preconfigured for RAID1.
Slot 2 is reserved for the optional software RAID1 configuration.
Note
Hot-swapping is supported with 2 SSDs. However, you must enter a CLI
command to remove one disk from the RAID before hot swapping. See the
CLI configuration guide for your software for the procedure.
Note
Storage
Displays the serial number and a QR code that points to the low touch provisioning
(LTP) guide.
Pullout asset card
On rear panelGrounding lug
On rear panelPower switch
Resets the system to factory default without requiring serial console access
The reset button is recessed. Press with a pin and hold longer than 5 seconds
to set the system back to the factory default.
Note
Reset button
Deployment Options
Here are some examples of how you can deploy the Secure Firewall 3100:
• As a firewall:
• At the enterprise internet edge in a redundant configuration
• At branch offices in either a high availability pair or standalone
• At data centers in a high availability pair or clustered, which serves the needs of smaller enterprises
• As a device that provides additional application control, URL filtering, or IPS/threat-centered capabilities:
• Behind an enterprise internet edge firewall in an inline configuration or as a standalone (requires
hardware fail-open network module support)
• Deployed passively off a SPAN port on a switch or a tap on a network, or standalone
• As a branch native SD-WAN solution that offers remote deployment and is managed over a 4G LTE
• As a VPN device:
• For remote access VPN
• For site-to-site VPN
Cisco Secure Firewall 3110, 3120, 3130, and 3140 Hardware Installation Guide
4
Overview
Deployment Options
