Cisco 3110 Hardware Installation Guide

Factory Reset Button Status
• Green, flashing—Flashes 5 seconds after
you depress the button.
• Off—Reset is complete.
4Management Port Status
The 1/10-Gb fiber management port has a bicolor
LED under the SFP cage that indicates
link/activity/fault:
• Off—No SFP.
• Green—Link up.
• Green, flashing—Network activity.
• Amber—SFP present, but no link.
3
Network Module 2 Port Status
• Green—Port is enabled, the link partner is
detected.
• Amber—Port is enabled, but the link partner
is not detected.
• Green, flashing—Port is enabled; network
activity is detected.
6Fiber Port Link/Activity Status
Each fiber port has one dual color LED under the
SFP cage.
• Off—No SFP.
• Green—Link up.
• Green, flashing—Network activity at >1G
is detected.
• Amber—No link or network failure.
5
Alarm Status
• Off—No alarms.
• Amber—Environmental error.
• Green—Status is ok.
8CDO Status
• Green, flashing slowly (twice in 5
seconds)—Cloud is connected.
• Green and amber, flashing—Cloud
connection failure.
• Green—Cloud is disconnected.
See the Easy Deployment Guide for
1000, 2100, or 3100 Series Cisco
Secure Firewalls for more information
on LTP.
Note
7
System Status
• Off—System has not booted up yet.
• Green, flashing quickly—System is booting
up.
• Green—Normal system function.
• Amber—System boot up has failed.
• Amber, flashing—Alarm condition, system
needs service or attention and may not boot
properly.
10SSD 1 Status
• Off—The SSD is not present.
• Green—The SSD is present; no activity.
• Green, flashing—The SSD is active.
• Amber—The SSD has a problem or failure.
9
Cisco Secure Firewall 3110, 3120, 3130, and 3140 Hardware Installation Guide
12
Overview
Front Panel LEDs
