Power LED below
This power LED has the same
behavior as the front panel LED. See
Front Panel LEDs, on page 11 for
more information.
Note
2Power on/off switch1
Power supply module 1 FAIL LED4Power supply module 13
Power supply module 1 connector6Power supply module 1 OK LED5
Dual fan module 18Dual Fan Module 1 LED7
Dual fan module 210Dual Fan Module 2 LED9
Power supply module 2 FAIL LED12Power supply module 211
Power supply module 2 connector14Power supply module 2 OK LED13
—Two-post grounding pad
The two-post grounding lug and two
screws are included in the accessory
kit.
Note
15
Power Switch
The power switch is located to the left of power supply module 1 on the rear of the chassis. It is a toggle
switch that controls power to the system. If the power switch is off but the power cord is plugged in and
the power supply is flashing green, the system is in standby position, and only the 3.3-V standby power
is enabled from the power supply module. The 12-V main power is OFF. When the switch is in the ON
position, the 12-V main power is turned on and the system boots.
Before you move the power switch to the OFF position, use the shutdown commands so that the system
can perform a graceful shutdown. This may take several minutes to complete. After the graceful shutdown
is complete, the console displays It is safe to power off now. Wait until the front panel
PWR LED flashes momentarily and is off before removing AC power.
See Front Panel LEDs, on page 11 for the PWR LED description. See the FXOS Configuration Guide
for more information on using the shutdown commands.
If you remove the system power cords before the graceful shutdown is complete, disk corruption can
occur. You can move the power switch to OFF before the shutdown. The system ignores it.
Caution
After removing power from the chassis by unplugging the power cord, wait at least 10 seconds before
turning power back ON. You want to keep the system power off, including the standby power, for 10
seconds.
Note
For More Information
Cisco Secure Firewall 3110, 3120, 3130, and 3140 Hardware Installation Guide
14
Overview
Rear Panel
