Page #45 background image
2-7
Catalyst 3750 Switch Hardware Installation Guide
OL-6336-10
Chapter 2 Switch Installation
Verifying Switch Operation
These standards provide guidelines for acceptable working environments and acceptable levels of
suspended particulate matter:
Network Equipment Building Systems (NEBS) GR-63-CORE
National Electrical Manufacturers Association (NEMA) Type 1
International Electrotechnical Commission (IEC) IP-20
Box Contents
The switch getting started guide on Cisco.com describes the box contents. If any item is missing or
damaged, contact your Cisco representative or reseller for support.
Tools and Equipment
You need to supply a number-2 Phillips screwdriver to rack-mount the switch.
Verifying Switch Operation
Before you install the switch in a rack, on a wall, or on a table or shelf, you should power on the switch
and verify that the switch passes POST. See the “Running Express Setup” section in the getting started
guide for the steps required to connect a PC to the switch and to run Express Setup.
Powering On the Switch and Running POST
If your configuration has an RPS, connect the switch and the RPS to the same AC power source. See the
“Power Connectors” section on page 1-25, and see the Cisco RPS documentation for more information.
Note Always set the RPS in standby mode when you are connecting devices to it and in active mode during
normal operation.
To power on the switch, connect one end of the AC power cord to the AC power connector on the switch,
and connect the other end of the power cord to an AC power outlet.
To power on a DC switch, see Appendix C, “Connecting to DC Power, for complete instructions.
Warning
Attach only the Cisco RPS model to the RPS receptacle:
PWR-RPS2300, PWR675-AC-RPS-N1=.
Statement 370
As the switch powers on, it begins the POST, a series of tests that runs automatically to ensure that the
switch functions properly. POST lasts approximately 1 minute.
When the switch begins POST, the System, the RPS, the Master, the Status, the Duplex, the Speed, and
the Stack LEDs turn green. (On the PoE switches, the PoE LED also turns green as POST begins.) The
System LED flashes green, and the other LEDs remain continuous green.
