Cisco 3G MicroCell User Manual

10
Advance to page 12.
Option B
High Speed Internet with Modem Attached to Computer
Note: If you normally use a USB cable to connect to your modem and computer,
refer to ‘Connect Your Devices with USB Cables?’ on page 8 for cabling alternatives.
Remove the sticker that covers the rear panel of your 3G MicroCell.
To ensure success, it is important to complete the steps below in order.
1. Disconnect your current Ethernet cable from the modem and reconnect it to the black port labeled `Computer’
on the 3G MicroCell.
2. Take the yellow Ethernet cable that came with the 3G MicroCell and connect one end to the yellow
port
port
labeled `Ethernet’ on the 3G MicroCell and the other end to the Ethernet port on your modem.
3. First, turn off power to your current internet equipment. Wait 1 minute, then turn on power to your Internet
equipment in the following order:
a) Modem
b) 3G MicroCell (Do this last – connect one end of the AC Power Adapter to the port labeled ‘Power’ on
the 3G MicroCell and connect the other end to an AC outlet.)
Ethernet Cable
(Included)
Modem
AT&T 3G MicroCell™
Open Port
2
3
2
Power
1
This end is attached
to your computer.
Do NOT unplug.
Connect AC power adapter last.

Cisco 3G MicroCell Specifications

General

Brand	Cisco
Model	3G MicroCell
Category	Extender
Language	English
