Cisco 3G MicroCell User Manual

11
Priority Mode Configuration
Option C
Remove the sticker that covers the rear panel of your 3G MicroCell.
To ensure success, it is important to complete the steps below in order.
This setup prioritizes 3G MicroCell connections over computer connections.
1. Connect one end of an Ethernet cable to your Internet port on your Wi-Fi router and the other end of the cable
to the port labeled ‘Computer’ on your 3G MicroCell.
2. Take the yellow Ethernet cable that came with your 3G MicroCell and connect one end to the yellow
port
port labeled
‘Ethernet’ on the 3G MicroCell and the other end to the Ethernet port on your modem.
3. First, turn off power to your current internet equipment. Wait one minute, then turn on power to your Internet
equipment in the following order:
a) Modem
b) 3G MicroCell (Connect one end of the AC Power Adapter to the connector labeled ‘Power’ on the 3G MicroCell
and connect the other end to an available AC outlet.)
c) Wi-Fi Router
AT&T 3G MicroCell™
Ethernet Cable
(Included)
Wi-Fi Router Modem
Open
Port
Open Port
2
3
2
1
Power
1
Advance to page 12.
