Cisco 4500M User Manual

13-5
Software Configuration Guide—Release 12.2(25)EW
OL-6696-01
Chapter 13 Configuring SmartPort Macros
Configuring Smart-Port Macros
The no form of the macro name global configuration command only deletes the macro definition. It
does not affect the configuration of those interfaces on which the macro is already applied. You can
delete a macro-applied configuration on an interface by entering the default interface interface-id
interface configuration command. Alternatively, you can create an anti-macro for an existing macro that
contains the no form of all the corresponding commands in the original macro. Then apply the
anti-macro to the interface.
The following sections illustrate how to apply and display the attachments on each of the supported
macros:
• cisco-desktop, page 13-5
• cisco-phone, page 13-6
• cisco-switch, page 13-6
• cisco-router, page 13-7
cisco-desktop
This example shows how to apply the cisco-desktop macro to interface Fast Ethernet interface 2/9:
Switch(config)# interface fastethernet2/9
Switch(config-if)# macro apply cisco-desktop $AVID 35
Switch(config-if)# end
Switch# show parser macro name cisco-desktop
Macro name : cisco-desktop
Macro type : customizable
# Basic interface - Enable data VLAN only
# Recommended value for access vlan (AVID) should not be 1
switchport access vlan $AVID [access_vlan_id]
switchport mode access
# Enable port security limiting port to a single
# MAC address -- that of desktop
switchport port-security
# Ensure port-security age is greater than one minute
# and use inactivity timer
# “Port-security maximum 1” is the default and will not
# Show up in the config
switchport port-security violation restrict
switchport port-security aging time 2
switchport port-security aging type inactivity
# Configure port as an edge network port
spanning-tree portfast
spanning-tree bpduguard enable
Switch# show parser macro description
Interface Macro Description
--------------------------------------------------------------
Fa2/9 cisco-desktop
--------------------------------------------------------------
Step 7
Switch# show parser macro
Verifies that the macro was created.
Step 8
Switch# show running-config
interface
interface-id
Verifies that the macro is applied to an interface.
Step 9
Switch# copy running-config
startup-config
(Optional) Saves your entries in the configuration file.
Command Purpose
