17-12
Software Configuration Guide—Release 12.2(25)EW
OL-6696-01
Chapter 17 Understanding and Configuring EtherChannel
Configuring EtherChannel
To configure the LACP system priority and system ID, perform this task:
This example shows how to configure the LACP system priority:
Switch# configure terminal
Switch(config)# lacp system-priority 23456
Switch(config)# end
Switch(config)#
Switch>show module
Mod Ports Card Type Model Serial No.
----+-----+--------------------------------------+-----------------+-----------
1 2 1000BaseX (GBIC) Supervisor(active) WS-X4014 JAB063808YZ
2 48 10/100BaseTX (RJ45) WS-X4148-RJ JAB0447072W
3 48 10/100BaseTX (RJ45)V WS-X4148-RJ45V JAE061704J6
4 48 10/100BaseTX (RJ45)V WS-X4148-RJ45V JAE061704ML
M MAC addresses Hw Fw Sw Status
--+--------------------------------+---+------------+----------------+---------
1 0005.9a39.7a80 to 0005.9a39.7a81 2.1 12.1(12r)EW 12.1(13)EW(0.26) Ok
2 0002.fd80.f530 to 0002.fd80.f55f 0.1 Ok
3 0009.7c45.67c0 to 0009.7c45.67ef 1.6 Ok
4 0009.7c45.4a80 to 0009.7c45.4aaf 1.6 Ok
This example shows how to verify the configuration:
Switch# show lacp sys-id
23456,0050.3e8d.6400
Switch#
The system priority is displayed first, followed by the MAC address of the switch.
Configuring EtherChannel Load Balancing
Note Load balancing can only be configured globally. As a result, all channels (manually configured, PagP,
or LACP) will use the same load balancing method.
To configure EtherChannel load balancing, perform this task:
Command Purpose
Step 1
Router(config)# lacp system-priority
priority_value
(Optional for LACP) Valid values are 1 through 65535.
Higher numbers have lower priority. The default is 32768.
Router(config)# no system port-priority
Reverts to the default.
Step 2
Router(config)# end
Exits configuration mode.
Step 3
Router# show lacp sys-id
Verifies the configuration.
Command Purpose
Step 1
Switch(config)# [no] port-channel load-balance
{src-mac | dst-mac | src-dst-mac | src-ip |
dst-ip | src-dst-ip | src-port | dst-port |
src-dst-port}
Configures EtherChannel load balancing.
Use the no keyword to return EtherChannel load
balancing to the default configuration.
