A-3
Cisco 7206 Installation and Configuration Guide
OL-5102-02
Appendix A Industry-Standard Wiring Plans
For smaller numbers of wires, such as wires for an individual telephone station or terminal, you may use
a second color-code scheme. Table A-2 lists this color code and the usual correspondence with the
paired-wire color code. The alternate color code is included because sometimes the station wire uses the
first three pairs of the standard color code (white-blue, blue-white, and so on), while other times it uses
the six alternate colored wires.
Table A-2 Second Color-Code Scheme for Smaller Numbers of Wires
Pair Number Wire Number Solid Color Stripe Color Alternate Color Pin Number
1 1 White Blue Green 4
1 2 Blue White Red 3
2 1 White Orange Black 2
2 2 Orange White Yellow 5
3 1 White Green White 1
3 2 Green White Blue 6
