Cisco 7200 VXR Installation and Configuration Guide
OL-5013-09
Chapter 1 Cisco 7200 VXR Product Overview
Field-Replaceable Units
BCM12500 CPU at 500Mhz, Implementation 1, Rev 0.1, 512KB L2 Cache
6 slot VXR midplane, Version 2.0
Input/Output Controller
This section describes five different models of I/O controllers. These models are distinguished from one
another by their Ethernet interface options.
Table 1-22 lists the I/O controllers by product number and
describes their differences.
Note For a description of the configuration commands you need to configure the different interfaces on your
I/O controller, refer to the Input/Output Controller Replacement Instructions document.
You can also identify your I/O controller model from a terminal by using the show diag slot 0 command.
(See the
“Viewing Your System Configuration” section on page 4-20.)
The I/O controllers consist of the following components and options:
• Ethernet, Fast Ethernet, or Gigabit Ethernet interface options
• Dual channels for local console and auxiliary ports
The console port has full data communications equipment (DCE) functionality and the auxiliary port
has full data terminal equipment (DTE) functionality.
• NVRAM for storing the system configuration and environmental monitoring logs
Note NVRAM uses lithium batteries to maintain its contents when disconnected from power.
Some I/O controllers use a static RAM (SRAM) component with an external lithium battery
to provide the same functionality as the NVRAM.
• Two PC Card (PCMCIA) slots that hold Flash Disks or PC Cards for storing the default Cisco IOS
software image
Ta b l e 1-22 I/O Controller Descriptions
Product Number Description
C7200-I/O-GE+E 1 Gigabit Ethernet and 1 Ethernet port; equipped with a GBIC receptacle for
1000 megabits per second (Mbps) operation and an RJ-45 receptacle for
10-Mbps operation. (See
Figure 1-15.)
C7200-I/O-2FE/E 2 autosensing Ethernet/Fast Ethernet ports; equipped with 2 RJ-45 receptacles
for 10/100-Mbps operation. (See
Figure 1-16.)
C7200-I/O-FE
1
1. The Product Number C7200-I/O-FE does not specify MII because both an MII and an RJ-45 receptacle are included.
1 Fast Ethernet port; equipped with an MII receptacle and an RJ-45 receptacle
for use at 100
Mbps full-duplex or half-duplex operation. Only 1 receptacle
can be configured for use at a time. (See
Figure 1-17 and Figure 1-18 .)
C7200-I/O Has no Fast Ethernet port. (See Figure 1-19 and Figure 1-20.)
C7200-I/O-FE-MII
2
2. The I/O controller with the Product Number C7200-I/O-FE-MII has a single MII Fast Ethernet receptacle only. Although still
supported by Cisco, this I/O controller with a single MII receptacle is no longer an orderable product as of May 1998.
1 Fast Ethernet port; equipped with a single MII receptacle. (See Figure 1-21.)
