Supported Hardware
Fan Trays
Note The fan trays required by the Supervisor Engine 720 are supported only with the power supplies listed
in the “WS-C6503, WS-C6503-E, and CISCO7603 Power Supplies” and “CISCO7603-S Power
Supplies” sections.
Note Enter the show environment status | include fan command or the show environment cooling command
to display information about the installed fan trays.
High-Capacity Fan Trays
These high-capacity fan trays support the Supervisor Engine 720.
Product ID
(append “=” for spares)
Power
Allocated at
42 V Product Description
Minimum
Software
Version
WS-C6503-E-FAN
1.37 A@42 V High-capacity fan tray for WS-C6503-E chassis 12.2(33)SRA
FAN-MOD-3HS
2.98 A@42 V High-capacity fan tray for WS-C6503 and CISCO7603 chassis 12.2(33)SRA
FAN-MOD-6HS
4.29 A@42 V High-capacity fan tray for CISCO7606 chassis 12.2(33)SRA
WS-C6506-E-FAN
2.35 A@42 V High-capacity fan tray for WS-C6506-E chassis 12.2(33)SRA
WS-C6K-6SLOT-FAN2
12 V fan High-capacity fan tray for WS-C6506 chassis 12.2(33)SRA
FAN-MOD-09
5.75 A@42 V High-capacity fan tray for WS-C6509-NEB-A and CISCO7609
chassis
12.2(33)SRA
WS-C6509-E-FAN
3.58 A@42 V High-capacity fan tray for WS-C6509-E chassis 12.2(33)SRA
WS-C6K-9SLOT-FAN2
12 V fan High-capacity fan tray for WS-C6509 chassis 12.2(33)SRA
WS-C6K-13SLT-FAN2
7.10 A@42 V High-capacity fan tray for WS-C6513 and CISCO7613 chassis 12.2(33)SRA
