Installation Guide for Cisco IP Phone with Multiplatform Firmware
Wall Mount Your 7800 Series Phones
Wall Mount Your Phone
Plug in the Ethernet cable, and the power adapter
(optional).
3
Press the phone îš¿rmly into the wall bracket and
slide the phone down until the tabs in the bracket
click into position.
4
Remove a 7861 Phone from the Wall Mount
447127
447128
447129
3
1
2
2
1
1
2
Use a screw driver or other device to disengage the tabs.
3
Lift the phone to release it from the wall bracket.
Pull the phone toward you.
