Cisco IP Phone 7960 and 7940 Series User Guide
78-10182-08
Chapter 1 Introducing Your Cisco IP Phone
Using the Handset, Headset, and Speakerphone
Figure 1-3 Using the Handset Rest
Related Topics
• Using the Handset, page 1-12
1
Set the handset aside and use your thumb and finger to grasp and pull out
the square plastic tab in the handset rest.
2
Rotate the tab 180 degrees.
3
Slide the tab back into the handset rest with the extension protruding from
the top of the tab.
Replace the handset in the rest. The tab hooks into a slot in the handset to
ensure that the handset will not slip out of the rest.
1 2 3
77354

Cisco 7960 Series Specifications

General

Lines	6
Protocol Support	SIP, SCCP
Speakerphone	Yes
Ethernet Ports	2 (10/100 Mbps)
Power Options	Power over Ethernet (PoE), AC adapter
Audio Codecs	G.711, G.729a
