Cisco 7961 User Guide

13
MartinezUnifiedSchoolDistrict
PhoneandVoicemailUsersGuideforCisco7961Phones

Expansion Module
An expansion module will be added to certain phones. It allows for up to 14 additional
lines. This will be most helpful to the administrative assistants. The display allows the
user to see if other users are on the phone and if they have voice mail. If the line is in
use the line button will glow red. A flashing yellow light indicates an incoming call to that
line. The Expansion Module must be plugged into an electrical wall jack.

Cisco 7961 Specifications

General

Line Buttons	6
Speakerphone	Yes
Network Protocol	SIP, SCCP
Display	320 x 222 pixels
Ethernet Switch	10/100BASE-T
Power Options	Power over Ethernet (PoE)
Audio Codec Support	G.711, G.729a, G.729ab, iLBC
Weight	3.5 lb (1.6 kg)
Dimensions	8.0 x 10.5 x 6.0 in. (203 x 267 x 152 mm)
