5-4
Cisco Aironet 1200 Series Access Point Hardware Installation Guide
OL-8370-04
Chapter 5 Upgrading the 5-GHz Radio Module
Removing a 5-GHz Radio Module
Step 4 Insert your fingers into the base (latch opening) of the 5-GHz radio module (closest to the access point)
and pull straight out from the access point (see Figure 5-3).
Figure 5-3 Removing the 5-GHz Radio Module
Step 5 For a radio module with built-in antenna, fold the antenna down (towards the attached radio card) and
insert the module into a static protected bag.
Step 6 For a radio module with connectors, insert the radio module into a static protected bag.
To install a new 5-GHz radio module, see the “
Installing a 5-GHz Radio Module” section on page 5-5.
