Cisco ASR 1001-HX Removing And Replacing

Step 5 Remove the three screws from the rear of the chassis as shown in the following figure.
Step 6 Rotate the fan tray slightly forward, and then lift it out of the chassis as shown in the following figure.
Removing and Replacing FRUs
24
Removing and Replacing FRUs
Removing the Fans from a Cisco ASR 1001-HX Router

Cisco ASR 1001-HX Specifications

General

Form Factor	1 RU
Rack Mountable	Yes
Redundant Power Supply	Optional
Operating Temperature	32 to 104°F (0 to 40°C)
Memory	16 GB
Power Supply	Internal AC or DC
Humidity	5% to 95% non-condensing
Ports	Built-in 8 x 1GE and 4 x 10GE (SFP+)
Maximum NAT sessions	Up to 4 million
