*For information about the DB-25 alarm
connector, how it works, and Cisco ASR
1000 route processor LEDs, see the xref
section.
Note: Shielded cables must be used to
connect to the DB-25 alarm connector on
both the AC and DC power supplies, in
order to comply with
FCC/EN55022/CISPR22 Class A
emissions requirements.
Removing the DC Power Supply from Cisco ASR 1013 Router
Before you can remove a DC power supply from the Cisco ASR 1013 Router, you must remove power from
the power supply. Follow these steps to remove power and the DC power supply from the chassis.
Make certain that the chassis ground is connected before you begin removing and installing the power supply.
Caution
SUMMARY STEPS
1. Before servicing the power supply, switch the circuit breaker Off in your equipment area. As an additional
precaution, tape the circuit breaker switch in the Off position.
2. Slip on the ESD-preventive wrist strap that was included in the accessory kit.
3. Switch the power supply circuit breaker switch to Off (O).
4. Locate the terminal block on the rear of the chassis on the power supply.
5. Remove the slotted plastic cover from the terminal block (see xref fig).
6. Loosen the four captive screws on the DC power supply.
7. Grasping the power supply handles, pull the power supply from the chassis.
8. Replace the DC power supply within five minutes.
DETAILED STEPS
Step 1 Before servicing the power supply, switch the circuit breaker Off in your equipment area. As an additional precaution,
tape the circuit breaker switch in the Off position.
Step 2 Slip on the ESD-preventive wrist strap that was included in the accessory kit.
Step 3 Switch the power supply circuit breaker switch to Off (O).
Step 4 Locate the terminal block on the rear of the chassis on the power supply.
The following figure shows the DC power supply terminal block and plastic cover.
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
102
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing the DC Power Supply from Cisco ASR 1013 Router

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
