Cisco ASR 1004 Replacing

What to do next
This completes the steps for removing the Cisco ASR1002-X DIMMs from the module.
Replacing the Cisco ASR1002-X Router DIMMs
This section lists the steps to replace the Cisco ASR1002-X Router DIMMs.
SUMMARY STEPS
1. Place the module on an antistatic mat or pad and ensure that you are wearing an antistatic device, such as
a wrist strap.
2. Position the module so that the faceplate is toward you and the edge connector is away from you.
3. Remove the new DIMM from the antistatic bag.
4. Hold the DIMM component-side up, with the connector edge (the metal fingers) closest to you. Hold the
ends of the DIMM between your thumb and forefinger. See the following figure.
5. Align the DIMM with the socket, and insert the connector edge into the socket. Note the two notches
(keys) on the connector edge of the DIMM. These keys are intended to ensure correct orientation of the
DIMM in the socket.
6. Note the orientation of the socket key on the DIMM and the DIMM socket, and gently push the DIMM
into the socket until the lever is flush against the side of the DIMM socket, and the DIMM edge connector
is fully inserted. If necessary, rock the DIMM gently back and forth to seat it properly. The following
figure shows how to install the DIMM in the socket.
7. When the DIMM is installed, check that the release lever is flush against the side of the DIMM socket.
If it is not, the DIMM might not be seated properly. If the DIMM appears misaligned, carefully remove
it according to the removal procedure and then reseat it in the socket. Push the DIMM firmly back into
the socket until the release lever is flush against the side of the DIMM socket.
8. Repeat Step 3 through Step 7 for the remaining DIMMs.
9. Replace the module.
DETAILED STEPS
Step 1 Place the module on an antistatic mat or pad and ensure that you are wearing an antistatic device, such as a wrist strap.
Step 2 Position the module so that the faceplate is toward you and the edge connector is away from you.
DIMMs are sensitive components that can be shorted by mishandling; they are susceptible to ESD damage.
Handle DIMMs by the edges only and avoid touching the pins.
Caution
Step 3 Remove the new DIMM from the antistatic bag.
Step 4 Hold the DIMM component-side up, with the connector edge (the metal fingers) closest to you. Hold the ends of the
DIMM between your thumb and forefinger. See the following figure.
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
38
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Replacing the Cisco ASR1002-X Router DIMMs

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
