Configuring Channelized SONET/SDH on the Cisco ASR 9000 Series Router
How to Configure Channelized SONET/SDH
HC-353
Cisco ASR 9000 Aggregation Services Router Interfaces and Hardware Component Configuration Guide
OL-26061-03
Step 20
encapsulation {frame-relay | hdlc | ppp}
Example:
Router(config-if)# encapsulation
frame-relay | hdlc | ppp
Specifies the encapsulation type with the one of the following
keywords:
frame-relay—Frame Relay network protocol
hdlc—High-level Data Link Control (HDLC) synchronous
protocol
ppp—Point-to-Point Protocol
Step 21
ipv4 ip-address mask
Example:
Router(config-if)# ip address 10.10.10.10
255.255.255.255
Assigns an IP address and subnet mask to the interface.
Step 22
no shutdown
Example:
RP/0/0/CPU0:router (config-if)# no
shutdown
Removes the shutdown configuration.
Note Removal of the shutdown configuration eliminates the
forced administrative down on the interface, enabling it to
move to an up or down state (assuming that the parent
SONET layer is not configured administratively down).
Step 23
end
or
commit
Example:
RP/0/0/CPU0:router(config-sonet)# end
or
RP/0/0/CPU0:router(config-sonet)# commit
Saves configuration changes.
When you issue the end command, the system prompts you to
commit changes:
Uncommitted changes found, commit them before
exiting(yes/no/cancel)?
[cancel]:
Entering yes saves configuration changes to the running
configuration file, exits the configuration session, and
returns the router to EXEC mode.
Entering no exits the configuration session and returns the
router to EXEC mode without committing the
configuration changes.
Entering cancel leaves the router in the current
configuration session without exiting or committing the
configuration changes.
Use the commit command to save the configuration changes to
the running configuration file and remain within the
configuration session.
Step 24
show controllers sonet interface-path-id
Example:
RP/0/0/CPU0:router# show controllers
sonet 0/1/1/0
Verifies the SONET controller configuration.
Command or Action Purpose
