Chapter 2 Functional Description
Ethernet Line Cards
Figure 2-24 8-Port 10-Gigabit Ethernet (8x10GE) 80-Gbps Line Rate Card Front Panel
1 Ejector lever (one of two) 4 Port 7 XFP cage
2 Port Status LED (one per port) 5 Line Card Status LED
3 Port 0 XFP cage 6 Captive installation screw (one of two)
194795
6
A9K-8T- B
STAT US
4
5
1
2
3
CLASS 1
LASER
0 123 5467
