Installing the Cisco ASR 920 Series Router

This chapter describes how to install the Cisco ASR 920 Series Router and includes the following sections:

• Prerequisites, on page 1

• Installing the Router in a Rack, on page 1

• Wall Mounting the Cisco ASR 920 Series Router, on page 8

• Install the AC Power Cables, on page 11

• Install the DC Power Supply, on page 13

• Connect SFP Modules, on page 16

• Connect Gigabit Ethernet Ports, on page 20

• Install the Chassis Ground Connection, on page 21

• Power Connection Guidelines, on page 23

• Connect Chassis to Network, on page 25

Prerequisites

Before installing the Cisco ASR 920 Series Router, it is important to prepare for the installation by:

• Preparing the site (site planning) and reviewing the installation plans or method of procedures (MOP).

See “Site Planning” section on page 2-9 .

• Unpacking and inspecting the Cisco ASR 920 Series Router. See “Receiving the Cisco ASR 920 Series

Router” section on page 2-20 .

• Gathering the tools and test equipment required to properly install the Cisco ASR 920 Series Router. See

“Tools and Equipment” section on page 2-21 .

For more instructions on how to prepare for the installation of the Cisco ASR 920 Series Router, see Chapter

2, “Preparing for Installation.”

Installing the Router in a Rack

The following sections describe how to install the Cisco ASR 920 Series Router in a rack. The procedures in

this section apply to both horizontal and vertical mounting of the router in a rack:
