Attaching Brackets for 23-Inch Racks
The following figure shows how to attach brackets for 23-inch racks on the router.
Figure 3: Attaching Brackets for 23-Inch Racks
Front-mounting position2Phillips flat-head screws1
Installing the Cisco ASR 920 Series Router
5
Installing the Cisco ASR 920 Series Router
Attaching Brackets for 23-Inch Racks
