Cisco ASR 920 series

Figure 2: Attaching Brackets for 19-Inch Racks
Front-mounting position2Phillips flat-head screws1
Rear-mounting position4Mid-mounting position3
Installing the Cisco ASR 920 Series Router
4
Installing the Cisco ASR 920 Series Router
Attaching Brackets for 19-Inch Racks
