The following tables show the PoE available and PoE requirements for PoE switch models.
Table 4: Available PoE with AC Power Supply
Full PoE with Redundant
Power Supply
Available PoEDefault Power SupplyModels
740W370WPWR-C5-600WACC9200-24P
1440W740WPWR-C5-1KWACC9200-48P
——PWR-C5-125WACC9200-24T
——C9200-48T
——C9200L-24T-4G
——C9200L-24T-4X
——C9200L-48T-4G
——C9200L-48T-4X
740W
370WPWR-C5-600WACC9200L-24P-4G
740W370WC9200L-24P-4X
1440W
740WPWR-C5-1KWACC9200L-48P-4G
1440W740WC9200L-48P-4X
The power supply modules have two status LEDs.
Table 5: Switch Power Supply Module LEDs
DescriptionPS OKDescriptionAC OK
Output is disabled, or input is outside
operating range (AC LED is off).
OffNo AC input power.Off
Power output to switch active.GreenAC input power present.Green
Output has failed.Red
Fan Modules
The Cisco Catalyst 9200 Series Switches supports two internal fixed 12-V fan modules and two field-replaceable
fan modules (C9200-FAN=). The C9200 models support modular fans whereas the C9200L models provide
two internal fixed fans.
For information about the type of fan module supported on different switch models, see Switch Models, on
page 1.
Cisco Catalyst 9200 Series Switches Hardware Installation Guide
9
Product Overview
Fan Modules

Cisco C9200L-48P-4G Specifications

General

Model	C9200L-48P-4G
Category	Switch
Uplink Interfaces	4 x 1G SFP
Switching Capacity	176 Gbps
PoE Budget	740W
Stacking Bandwidth	80 Gbps
Enclosure Type	Rack-mountable - 1U
Power Over Ethernet (PoE)	Yes
RAM	2 GB
Flash Memory	4 GB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Ports	48 x 10/100/1000 PoE+
MAC Address Table Size	16K
Jumbo Frame Support	Yes
Routing Protocol	RIP
Remote Management Protocol	SNMP
Features	Quality of Service (QoS), VLAN support, Access Control List (ACL) support, DHCP snooping, IPv6 support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3af, IEEE 802.3at
Operating Temperature	0 to 40 °C
Operating Humidity	10 to 90% non-condensing
