Cisco C9200L-48P-4G User Manual

Weight does not include the functional uplink modules, the blank modules, or the power supplies
Table 18: Weight Measurements
WeightSwitch Model
10 lb (4.5 kg)C9200-24T
10 lb (4.5 kg)C9200-24P
10 lb (4.5 kg)C9200-48T
10 lb (4.5 kg)C9200-48P
9.6 lb (4.35 kg)C9200L-24T-4G
9.6 lb (4.35 kg)C9200L-24P-4G
9.6 lb (4.35 kg)C9200L-48T-4G
9.6 lb (4.35 kg)C9200L-48P-4G
9.0 lb (4.08 kg)C9200L-48T-4X
9.5 lb (4.31 kg)C9200L-48P-4X
8.5 lb (3.9 kg)C9200L-24P-4X
8.0 lb (3.63 kg)C9200L-24T-4X
This table describes the physical specifications.
Table 19: Physical Specifications for the Power Supplies
Weight
2 lb (0.9 kg)
PWR-C5-1KWAC
1.7 lb (0.77 kg)PWR-C5-600WAC
1.5 lb (0.68 kg)PWR-C5-125WAC
Dimensions (H x D x W)
The dimensions shown include the extraction handle and the keying feature.
1.58 x 4.0 x 7.6 in. (40.1 X 101.6 X 193 mm)
PWR-C5-1KWAC
PWR-C5-600WAC
PWR-C5-125WAC
Cisco Catalyst 9200 Series Switches Hardware Installation Guide
71
Technical Specifications
Technical Specifications

Cisco C9200L-48P-4G Specifications

General

Model	C9200L-48P-4G
Category	Switch
Uplink Interfaces	4 x 1G SFP
Switching Capacity	176 Gbps
PoE Budget	740W
Stacking Bandwidth	80 Gbps
Enclosure Type	Rack-mountable - 1U
Power Over Ethernet (PoE)	Yes
RAM	2 GB
Flash Memory	4 GB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Ports	48 x 10/100/1000 PoE+
MAC Address Table Size	16K
Jumbo Frame Support	Yes
Routing Protocol	RIP
Remote Management Protocol	SNMP
Features	Quality of Service (QoS), VLAN support, Access Control List (ACL) support, DHCP snooping, IPv6 support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3af, IEEE 802.3at
Operating Temperature	0 to 40 °C
Operating Humidity	10 to 90% non-condensing
