CHAPTER 1
Product Overview
The Cisco Catalyst 1000 Series switches are fixed-configuration, Gigabit Ethernet switches that provide
entry-level enterprise-class Layer 2 access for branch offices, conventional workspace, and out-of-wiring
closet applications.
Cisco Catalyst 1000 Series switches provide support for the following features:
• 24 or 48 Gigabit Ethernet ports with line-rate forwarding performance.
• 4 Gigabit Small Form-Factor Pluggable (SFP/SFP+) uplinks.
• Power over Ethernet Plus (PoE+) support with up to 370W of PoE budget and Perpetual PoE.
• Fanless operation with operational temperature up to 50°C for deployment outside the wiring closet.
• Reduced power consumption and advanced energy management.
• RJ-45 and USB Mini-Type B console ports.
• USB Type A port supports file system.
• Switch Models, on page 1
• Front Panel, on page 2
• Rear Panel, on page 7
• Network Configurations, on page 9
Switch Models
Table 1: Cisco Catalyst 1000 24-Port and 48-Port Switch Models and Description
DescriptionSwitch Model
24 10/100/1000 Ethernet ports; four 1-Gigabit Ethernet small form-factor pluggable
(SFP) module uplink slots
C1000-24T-4G-L
24 10/100/1000 PoE+ ports (PoE budget of 195W); four 1-Gigabit Ethernet SFP
module uplink slots
C1000-24P-4G-L
24 10/100/1000 PoE+ ports (PoE budget of 370W); four 1-Gigabit Ethernet SFP
module uplink slots
C1000-24FP-4G-L
Cisco Catalyst 1000 Series 24-Port and 48-Port Switch Hardware Installation Guide
1

Cisco Catalyst 1000 Series Specifications

General

Series	Catalyst 1000
Category	Switch
Switching Capacity	Up to 104 Gbps
Operating Temperature	-5°C to 45°C
Storage Temperature	-25°C to 70°C
Ports	8, 16, 24, or 48 Gigabit Ethernet ports
Layer	Layer 2
Power over Ethernet	PoE+
Management	Web UI, CLI
MAC Address Table Size	8000 entries
Jumbo Frames	Up to 9216 bytes
Mounting	Rack-mountable, desktop
Stacking	No
Security Features	802.1x, DHCP Snooping
Relative Humidity	10% to 90% non-condensing
Power Supply	Internal
