Cisco Catalyst 1000 Series User Manual

CONTENTS
Preface vii
PREFACE
Document Conventions vii
Obtaining Documentation and Submitting a Service Request ix
Product Overview 1
CHAPTER 1
Switch Models 1
Front Panel 2
PoE Ports 4
10/100/1000 Ports 4
Console Ports 4
USB Type A Port 5
SFP Module Slots 5
LEDs 6
System LED 7
Port LEDs 7
Rear Panel 7
Internal Power Supply 8
Security Slot 9
Network Configurations 9
Switch Installation 11
CHAPTER 2
Safety Warnings 11
Box Contents 15
Tools and Equipment 16
Installation Guidelines 17
Cisco Catalyst 1000 Series 24-Port and 48-Port Switch Hardware Installation Guide
ii
Contents

Cisco Catalyst 1000 Series Specifications

General

Series	Catalyst 1000
Category	Switch
Switching Capacity	Up to 104 Gbps
Operating Temperature	-5°C to 45°C
Storage Temperature	-25°C to 70°C
Ports	8, 16, 24, or 48 Gigabit Ethernet ports
Layer	Layer 2
Power over Ethernet	PoE+
Management	Web UI, CLI
MAC Address Table Size	8000 entries
Jumbo Frames	Up to 9216 bytes
Mounting	Rack-mountable, desktop
Stacking	No
Security Features	802.1x, DHCP Snooping
Relative Humidity	10% to 90% non-condensing
Power Supply	Internal
