Cisco Catalyst 1000 Series User Manual

Verifying Switch Operation 17
Installing the Switch 18
Rack-Mounting 18
Attaching the Rack-Mount Brackets 19
Mounting a 24-Port or 48-Port Switch in a Rack 21
Wall-Mounting 22
Attaching the Brackets for Wall-Mounting 22
Mounting on a Wall 23
Installing the Switch on a Table or Shelf 24
After Switch Installation 25
Installing the Power Cord Retainer (Optional) 25
Installing SFP Modules 27
Installing an SFP or SFP+ Module 27
Removing an SFP or SFP+ Module 29
Connecting to SFP or SFP+ Modules 30
Connecting to Fiber-Optic SFP or SFP+ Modules 30
Connecting to 1000BASE-T SFP 31
10/100/1000 PoE+ Port Connections 32
10/100/1000 Ethernet Port Connections 33
Auto-MDIX Connections 33
Troubleshooting 35
CHAPTER 3
Diagnosing Problems 35
Switch POST Results 35
System LEDs 35
Switch Connections 35
Bad or Damaged Cable 35
Ethernet and Fiber-Optic Cables 36
Link Status 36
10/100/1000 Port Connections 36
10/100/1000 PoE+ Port Connections 36
SFP and SFP+ Module 37
Interface Settings 37
Ping End Device 37
Cisco Catalyst 1000 Series 24-Port and 48-Port Switch Hardware Installation Guide
iii
Contents

Cisco Catalyst 1000 Series Specifications

General

Series	Catalyst 1000
Category	Switch
Switching Capacity	Up to 104 Gbps
Operating Temperature	-5°C to 45°C
Storage Temperature	-25°C to 70°C
Ports	8, 16, 24, or 48 Gigabit Ethernet ports
Layer	Layer 2
Power over Ethernet	PoE+
Management	Web UI, CLI
MAC Address Table Size	8000 entries
Jumbo Frames	Up to 9216 bytes
Mounting	Rack-mountable, desktop
Stacking	No
Security Features	802.1x, DHCP Snooping
Relative Humidity	10% to 90% non-condensing
Power Supply	Internal
