Figure 10: Attaching 19-inch Brackets to a 24-Port and 48-Port Cisco Catalyst 1000 Switch

Mid-mounting position3Front-mounting position1

Cisco Catalyst 1000 Series 24-Port and 48-Port Switch Hardware Installation Guide

20

Switch Installation

Attaching the Rack-Mount Brackets
