Cisco Catalyst 2960-X Hardware Installation Guide

CHAPTER 1
Product Overview
The Catalyst 2960-X and 2960-XR family of switches are Ethernet switches to which you can connect devices
such as Cisco IP Phones, Cisco Wireless Access Points, workstations, and other network devices such as
servers, routers, and other switches.
Some models of the switches support stacking through the Cisco FlexStack-Plus technology. Unless otherwise
noted, the term switch refers to a standalone switch and to a switch stack.
This chapter contains these topics:
•
Switch Models, page 1
•
Front Panel, page 3
•
Rear Panel, page 15
•
Management Options, page 20
•
Network Configurations, page 21
Switch Models
Table 1: Catalyst 2960-X Switch Models and Descriptions
Description
Supported
Software
Switch Model
48 10/100/1000 Power over Ethernet Plus (PoE+) ports (PoE
budget of 740 W) and 2 small form-factor pluggable (SFP)+
2
module slots.
LAN BaseCatalyst 2960X-48FPD-L
1
48 10/100/1000 PoE+ ports (PoE budget of 370 W) and 2
SFP+ module slots.
LAN BaseCatalyst 2960X-48LPD-L
1
24 10/100/1000 PoE+ ports (PoE budget of 370 W) and 2
SFP+ module slots.
LAN BaseCatalyst 2960X-24PD-L
1
Catalyst 2960-X and 2960-XR Switch Hardware Installation Guide
OL-28309-02 1

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
