Page #94 background imageLoading...
Page #94 background image
If you have stacked your switches, connect to the console port of one of the switches in the stack. You
can initially configure the entire stack from any member switch.
Note
Connecting the RJ-45 Console Port
Procedure
Step 1
Connect the RJ-45-to-DB-9 adapter cable to the 9-pin serial port on the PC. Connect the other end of the cable
to the switch console port.
Step 2
Start the terminal-emulation program on the PC or the terminal. The program, frequently a PC application
such as HyperTerminal or ProcommPlus, makes communication between the switch and your PC or terminal
possible.
Step 3
Configure the baud rate and character format of the PC or terminal to match the console port default
characteristics:
9600 baud
8 data bits
1 stop bit
No parity
None (flow control)
Step 4
Power on the switch as described in the switch getting started guide.
Step 5
The PC or terminal displays the bootloader sequence. Press Enter to display the setup prompt. Follow the
steps in Entering the Initial Configuration Information, on page 89.
Catalyst 2960-X and 2960-XR Switch Hardware Installation Guide
84 OL-28309-02
Configuring the Switch with the CLI-Based Setup Program
Connecting the RJ-45 Console Port

Table of Contents

Other manuals for Cisco Catalyst 2960-X

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cisco Catalyst 2960-X and is the answer not in the manual?

Cisco Catalyst 2960-X Specifications

General IconGeneral
Console portRJ-45
USB 2.0 ports quantity2
SFP module slots quantity4
Installed SFP modules quantity-
Gigabit Ethernet (copper) ports quantity48
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Power sourceAC
Input current5 A
AC input voltage100 - 240 V
Power consumption (typical)60.9 W
Number of power supply units1
Redundant power supply (RPS) supportYes
Operating altitude0 - 3000 m
Non-operating altitude0 - 4000 m
Storage temperature (T-T)-25 - 70 °C
Operating temperature (T-T)-5 - 40 °C
Operating relative humidity (H-H)10 - 95 %
Switching protocolsUDP, TCP, RADIUS/TACACS+
Number of VLANs1023
Networking standardsIEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput107.1 Mpps
Jumbo frames9216
Number of queues8
MAC address table16000 entries
Number of static routes1000
DHCP featuresDHCP server
AuthenticationMAC-based authentication, Port-based authentication
Security algorithms802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules3
Switch typeManaged
Switch layerL2/L3
SafetyUL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor1U
Product colorBlack
Total Power over Ethernet (PoE) budget370 W
Power over Ethernet (PoE) ports quantity24
Power over Ethernet plus (PoE+) ports quantity12
Memory typeDRAM
Noise level39 dB
Flash memory128 MB
Internal memory512 MB
Processor frequency600 MHz
Mean time between failures (MTBF)276870 h
Weight and Dimensions IconWeight and Dimensions
Depth368 mm
Width445 mm
Height45 mm
Weight5800 g
